Specialist in Leftovers

TR

Specifications

Working width (m)

from 1.8 to 3.6

Range

Pasture Toppers

TR General Points

General Points

Since its introduction on the market in the mid-80s, the TR rotary pasture topper has very quickly become a real reference in the professional world. Very good at mowing on most open spaces, it is also highly appreciated for its excellent performance in pasture care. Its multirotor system with offset enables it to work on areas with more compact leftovers, while keeping a constant work flow. Available in rear (TR), front (ATR) or offset (DTH) position, JOSKIN toppers easily adapt to all situations!

Specifications

TR Quality Cut

Quality Cut

JOSKIN has designed removable and retractable floating blades in order to provide a high-quality performance. They retract when striking into hard obstacles. This technical choice spares the transmission and provides the tractor with a maximal protection against shocks. The aim of the TR topper design is to maximise the “tornado” effect created by the powerful rotation of the rotors. The vegetation is thus powerfully sucked upwards and held in the movement of the knives, even in the event of damp weather. Once finely chopped, the grass is uniformly spread by means of the deflectors on the frame.

TR Perfect Follow-up of the Land

Perfect Follow-up of the Land

Whether front- (ATR) or rear-mounted, all our rotary pasture toppers are fitted with a floating hitch allowing to perfectly follow the ground relief for a maximal precision of performance. Each TR topper is fitted with 2 XXL skids allowing the machine to perfectly glide, even on an uneven ground. The horizontal angle of the cut is therefore ensured in all circumstances, without any risk of accidental contact between the knives and the ground.

TR Adjustable Cutting Height

Adjustable Cutting Height

All frames of the range are fitted with a system to adjust the cutting height on 8 positions in order to adapt to the conditions encountered during the different periods of the year. A large clearance between the blades and the frame ensures an outstanding air flow and an optimal mixing of the cut material, without any risks of blockage or loss of speed, as well as a smooth and efficient work.

TR Easy Maintenance

Easy Maintenance

All our rotary pasture toppers are coated with an anti-corrosion paint providing a long-term protection against external aggressions. The simple and timeless design of their frame prevents water from stagnating and makes the cleaning operations easier. Simply using a high-pressure cleaner will be enough to get an implement back in its original state.

TR 100% Safe Use

100% Safe Use

All JOSKIN frames are fitted with a large range of safety devices (no access to the knives in working position, protection plates, discs to prevent the knives to rub on hard surfaces, etc.) so that you can only serenely focus on your work.

Special Features

Pictures TR 1
Pictures TR 2
Pictures TR 3
Pictures TR 4
Pictures TR 5
Pictures TR 6
Pictures TR 7
Pictures TR 8
Pictures TR 9
Pictures TR 10
Pictures TR 11
